Moky

1

Dimension   (L*W*H)

2480mm×   1520mm×   1550mm

2

Weight   of vehicle (with battery)

677   kg

3

FRAME

Aluminum   Frame

4

Min   ground clearance

150mm

5

Rated   member

2   persons

6

Wheelbase

1630   mm

7

Track   Tread(F/R)

1250/1350mm

8

Brake   Type(F/R)

Disc/   Drum

9

Brake   system operating type

Pedal   brake

10

Rim   type（F/R）

13×5.5

11

Tire   size（F/R）

155/65R13

12

Tire   pressure（F/   R）

250Kpa

13

Max.   Speed

45Km/h

14

Economical   speed

35Km/h

15

Brake   distance

≤18m when fully   loaded & speed under 45 Km/h

16

Climbing   ability

Gradient   20%

17

Min   Round radius

≤10m

18

Rated   power of driving motor

4KW

19

Type   of driving motor

DC   Brushless

20

Nominal   battery voltage

72V

21

Specification   of battery

12V-120Ah/   unit×6 units

22

Type   of battery

Lead-acid   gel maintenance-free battery

23

Weight   of battery

240   KGS

24

Charger   specification

Input   voltage： AC220V~240V

25

Per   Charging time

8-10h

26

Customization

Yes
